LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later

Product Categories
Hangfan Electric Power Co.,Ltd
Contact Now

LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later

Place of Origin : Guangdong, China

Brand Name : aobest

Model Number : LXAP-70/120

Voltage : 480V

Current : 300A

Certificate : ISO9001:2008

Standard : IEC60529 EN60309

Color : Green

MOQ : 1000 pieces

Price : $8.50/pieces >=1000 pieces

Contact Now

Product Description

China high quality glass insulator LXAP-70/120


LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later
LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later
LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later
LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later
LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later
Details

LXAP-160/240

Currency designation
U70BP/146M
U100BP/127M
U120BP/127M
U120BP/146M
Designation
LXAP-70
LXAP-100
LXAP1-120
LXAP-120
(mm)Diameter D
380
380
380
380
(mm)Spacing H
146
146
127
146
(mm)Creepage L
365
365
365
365
(mm)Socket soupling
16
16
16
16
(KN)Mechanical failing Load
70
100
120
120
(KN)Mechanical routine test
35
50
60
60
(KV)Wet Power frequency withstand voltage
45
45
45
45
(KV)Dry lighting impulse withstand voltage
90
90
90
90
(P.U)Impulse puncture voltage
2.8
2.8
2.8
2.8
(KV) Power frequency puncture voltage
130
130
130
130
(μV)Rodio influence voltage
50
50
50
50
(KV)Corona visual test
18/22
18/22
18/22
18/22
power frequency electric arc voltage
0.12s/20kA
0.12s/20kA
0.12s/20kA
0.12s/20kA
(kg)Net weight per unit
5.3
5.2
5.3
5.4
Packing & Delivery
LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later
LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later
LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later
LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later
LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later
LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later
LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later
Our Service

*Any inquiries will be replied within 24 hours.
*OEM/ODM available.
1) Printing your logo on the cable.
2) Printing your logo on the pull box, wooden drum according to your design
3) Any your idea on cable, packing box are available.
*High quality, reasonable and competitive price, fast lead time.
1) All products will have been strictly Quality Checked in house before packing.
2) All products will be well packed before shipping.
*Faster delivery.:Sample order in stock, and 3-7 days for bulk production.
*Strong technical support (technical data, drawing, etc.)
*Free sample is available with economic express fee.
*Payment:We can accept payment methods: L/C, T/T, Western Union,other payment can negotiation.

Our Company
LXAP-70/120 Glass Insulator for Power Distribution Equipment and 480V Voltage Pay Later

Zhengzhou Aobest Electronic Technology Co., Ltd. is a professional company, located in Zhengzhou, China. We provide power cables and wires. We are a manufacturer producing wire and cables in China. Quality goes first, we pay highly attention to it. For every step we have the strict quality control and inspection. Every month we have 30containers exported and have the long term and stable customers.

FAQ

Q: Could you offer the Type Test Report?
A -Yes, we could offer the Type Test Report issued by Chinese laboratories.

Q:Have you ever supplied the cables to our country?
A: -Our cables have been supplied to many countries and regions, such as, Singapore, Taiwan, Hong Kong, Kenya, Congo, France, Cyprus, Honduras, etc.

Q: According to which standards can you produce cables?
A: -GB/T, IEC, EN.

Q: What is your MOQ?
A: -The MOQ is different, as the different cable type.

Q: Do you have ready cables?
A: -Some normal cables have the inventory, most cables are produced according to your requirements.

Q: What's the tolerance of delivery length for each coil?
A: -±0.005m.

Q: What are your main products?
A: -Our main products are the PVC insulated cable, power cable, and electric wire.
