High Quality Steel Wire Armored Direct Burial Armored Cable 120 mm2

Name: High Quality Steel Wire Armored Direct Burial Armored Cable 120 mm2
Brand: Aobest
Price: 100.00 USD

Cheap High Quality Steel Wire Armored Direct Burial Armored Cable 120 mm2 for sale

Place of Origin : Henan, China

Brand Name : Aobest

Model Number : swa power cable

Insulation Material : PVC

Type : LOW VOLTAGE, SWA cable

Application : Construction

Conductor Material : Copper

Jacket : PVC

Size : 35mm2

Product name : Underwater Cable 120 mm2

Certificate : CE/ISO9001/ISO14001 /OHSAS18001/CCC

Standard : BS IEC ASTM DIN

Package : Steel-wooden Drum

Color : Black

Packaging Details : export standard steel-wooden drum or as your request

Port : Qingdao or Shanghai

Supply Ability : 5000 Kilometer/Kilometers per Month

Price : $100.00 - $1,000.00/kilometers

Contact Now

High Quality Steel Wire Armored Direct Burial Armored Cable 120 mm2 direct burial armored cable

Application:

PVC insulation, thin steel-wire armor, PVC sheath power cable is adapt to the well, underwater with the bottom of sea ,the cable can bear the bigger pressure with lead to pull the dint.

Standards: IEC502, IEC332-3

Conductor: Cu

Insulation: PVC (Premature Ventricular Contraction)

Armored: Steel wire

Sheath: PVC (Premature Ventricular Contraction)

Sheath Color: Black or Gray (Bespoke cable)

Bending Radius: 8D ± 0.05

Temperature Rating: 0°C to 70°C

0.6/1kV 3-core Cu/PVC/SWA/PVC Cable
Nominal cross sectional area of conductor(mm²)	Steel wire thickness(mm)	Approx, overall diameter(mm)
3×25	/	24.5
3×50	/	30.2
3×70	/	34.1
3×120	/	42.0
3×150		45.9
3×240	/	55.4
3×300	/	60.6

Application:

PVC insulation, thin steel-wire armor, PVC sheath power cable is adapt to the well, underwater with the bottom of sea ,the cable can bear the bigger pressure with lead to pull the dint.

Standards: IEC502, IEC332-3

Conductor: Cu

Insulation: PVC (Premature Ventricular Contraction)

Armored: Steel wire

Sheath: PVC (Premature Ventricular Contraction)

Sheath Color: Black or Gray (Bespoke cable)

Bending Radius: 8D ± 0.05

Temperature Rating: 0°C to 70°C

0.6/1kV 4-core Cu/PVC/SWA/PVC Cable
Nominal cross sectional area of conductor(mm²)	Steel wire thickness(mm)	Approx, overall diameter(mm)
4×25	/	27.1
4×50	/	34.4
4×70	/	37.9
4×120		46.9
4×150	/	51.8
4×240	/	62.3
