China High Quality Gold Supplier Flexible Copper Cable Low Voltage Rubber for Industrial Use

Name: China High Quality Gold Supplier Flexible Copper Cable Low Voltage Rubber for Industrial Use
Brand: Aobest
Price: 1.00 USD

Cheap China High Quality Gold Supplier Flexible Copper Cable Low Voltage Rubber for Industrial Use for sale

Place of Origin : Henan, China

Brand Name : Aobest

Model Number : MY,MYP,MYPTJ,MC,MCP,MYQ

Insulation Material : Rubber

Type : LOW VOLTAGE

Application : Industrial

Conductor Material : Copper

Jacket : Rubber

Brand : Aobest

Product name : high quality rubber flexible cable

Color : Requirement

Certificate : ISO9001/ISO14001 /OHSAS18001/CCC

Conductor : copper

Insulation : rubber

MOQ : 1000 meters

Price : $1.00 - $10.00/meters

Contact Now

Universal Rubber Flexible Cable

First: Implemented standard

GB5013-1997(The rated voltage of Rubber insulate cable is 450/750v and under that), JB8735-1998 (The rated voltage of Rubber insulate cable and flexible cable is 450/750and which is under that)

Second: Application characteristics

The allowed long-term working temperature of the cable is 60°C

Third: cable type

Type	Name	Application
245IEC53(YZ)	Common Rubber Flexible Cable	Used in the all kinds of movable electrical appliance or instrument
245IEC57(YZW)	Common Chloroprene Rubber sheathed Flexible cable
YZ YZW	Medium Type Rubble Sheathed Flexible cable	Used in the all kinds of movable electrical appliance which can bear bigger external force of machine
245IEC66(YCW)	Heavy Type Rubble Sheathed flexible cable for Using Outdoor
YC	Heavy Type Rubber Sheathed Flexible cable
YCW	Heavy Type Rubber Sheathed Flexible Cable for Using Outdoor

Forth: Specification

Type	Rated voltage(v)	No. of cores	nominal cross-section
245IEC53(YZ)	300/350	2, 3, 4, 5	0.75-2.5
245IEC57(YZW)		2, 3, 4, 5	0.75-2.5
YZ YZW		2, 3, 4, 5	4-6
		4(three in bigger and one in little )	1.5-6
		4(three in bigger and one in little )	0.75-6
245IEC66(YCW)	450/750	1	1.5-400
		2	1.0-25
		3	1.0-95
		4	1.0-150
		5	1.0-25
YC		1	1.5-400
		2	1.5-95
		3,4	1.5-150
		5	1.5-25
		4(three in bigger and one in little )	2.5-150
YCW		2	35-95
		3	120-150
		4(three in bigger and one in little )	2.5-150

China High Quality Gold Supplier Flexible Copper Cable Low Voltage Rubber for Industrial Use

Please contact me freely; maybe I’ll give you a big surprise. ^.^
